Good reason to install an inline fuse on a Harman pellet stove igniter

Discussion in 'Pellet Stoves, Pellet Fireplaces, Pellet Furnaces' started by don2222, Sep 2, 2020.

  1. don2222

    don2222

    Joined:
    Nov 10, 2013
    Messages:
    3,315
    Likes Received:
    4,567
    Location:
    Salem NH
    Hello
    The igniter stopped working and the 4 amp igniter fuse blew That I installed on the yellow wire.
    The Circuit board was good, the vacuum switch was good, so I dropped the igniter cradle and to my surprise saw this!
    See pic 1 !! So just taped up the wire and replaced the fuse! No burned out control panel! Igniter is still good!!!
    Pic 1 - igniter wire exposed and shorted to cradle! Actually the wire was stuck to the cradle!
    Pic 2 - Inline fuse holder with 4 amp fuse
    Pic 3 - Igniter cradle
    Pic 4 - Harman Advance Igniter works!
    Pic 5 - Fire!
