Lil House Heater / Barrel Stove

Discussion in 'OWB's and Gasification Boilers' started by Snerdguy, Aug 15, 2019.

  1. Snerdguy

    Snerdguy

    Joined:
    Aug 14, 2019
    Messages:
    2
    Likes Received:
    9
    Location:
    Ohio
    For those unfamiliar, it's basically a barrel stove wrapped in an insulated jacket with a blower to move heat into the house. I was doing my routine maintenance and replacing gaskets. The barrel seemed plenty solid all over even after a number of years use. That is, until I took the smoke stack adapter off and found that the barrel rusted through underneath it. That's the only rust through.

    Now, I have to decide. Should I have a metal plate welded over the rusted out area or should I get a new barrel that will have to be cut and refitted and the paint burned off? I have to wonder if I can get as heavy gauge of a barrel since the used ones they sell at Rural King seem rather light. Anyone have suggestions?

  2. CDF_USAF

    CDF_USAF

    Joined:
    Oct 20, 2013
    Messages:
    144
    Likes Received:
    652
    Location:
    Dover DE
    Is this a 55 gal drum stove? If it is, I'd hit up some industrial areas, they would have heavier drums.

  3. Highbeam

    Highbeam

    Joined:
    Jun 25, 2014
    Messages:
    1,274
    Likes Received:
    3,751
    Location:
    Cascade Foothills, wet side of WA
    Tractor maintenance shops (like John Deere dealerships) purchase lots of hydraulic oil in very heavy steel drums with closed tops. They love to give them away.

  4. Eric VW

    Eric VW Moderator

    Joined:
    Jan 6, 2015
    Messages:
    21,788
    Likes Received:
    121,589
    Location:
    Southwest VA
    Welcome aboard Snerdguy :salute:
    Although we sold our little piece of property in the Catskills a few years ago, we had a 33 gallon drum stove in the tiny cabin for just shy of 35 years. :eek:
    Look to see if you can find a stainless steel drum and you’ll be set for many years to come.
    I don’t know how well welds will hold up if decide to revamp your current setup.
    If it were me in your shoes and the only option was to keep and repair, I’d have a piece of 1/4” steel rolled to match drum shape and use a ceramic fiber blanket gasket, bolted thru with stainless hardware.
    :yes:

  5. Eric VW

    Eric VW Moderator

    Joined:
    Jan 6, 2015
    Messages:
    21,788
    Likes Received:
    121,589
    Location:
    Southwest VA
    Heck, even scavenging a chunk of another drum skin would work. And it’s already the correct curvature. If the collar is still intact and sound, it would bolt thru the repair piece, which as I said above would be bolted to the drum, with a gasket.

  6. SKEETER McCLUSKEY

    SKEETER McCLUSKEY

    Joined:
    Aug 6, 2015
    Messages:
    5,187
    Likes Received:
    27,036
    Location:
    Taconic Range
    go big or go home:rofl: :lol::rofl: :lol:

    brenndatomu, Chaz and Eric VW like this.
  7. Chaz

    Chaz

    Joined:
    Jan 27, 2018
    Messages:
    7,370
    Likes Received:
    51,817
    Location:
    Southwestern NY
    brenndatomu and Eric VW like this.
  8. TurboDiesel

    TurboDiesel

    Joined:
    Nov 22, 2013
    Messages:
    13,252
    Likes Received:
    76,668
    Location:
    Hollidaysburg Pa
    BrianK has played with a lot of barrels.
    I'll give him a call and see where he got his. They were nice and the sides were not ribbed.

  9. TurboDiesel

    TurboDiesel

    Joined:
    Nov 22, 2013
    Messages:
    13,252
    Likes Received:
    76,668
    Location:
    Hollidaysburg Pa
  10. BrianK

    BrianK

    Joined:
    Oct 3, 2013
    Messages:
    2,803
    Likes Received:
    9,210
    Location:
    West central PA
    I simply found “straight sided 55 gallon barrels” on a regional Craigslist search app I use called CPlusforCraigslist. I set it up to search statewide areas. Most of the guys I found selling them were picking them up in lots from manufacturing facilities then reselling them online. Mine were used for silicone based clear lubricant and I picked them up used once from a local reseller. The nice thing about the straight sided barrels is they were several gauges thicker than ribbed barrels.

    That said, it sounds like your original barrel is still pretty much intact, so I’d agree with the recommendations above to just find a similar barrel, cutt out the section needed, line it with come thin ceramic blanket (to make it relatively air tight) and bolt it in place through the original barrel with good quality stainless bolts and nuts.

    brenndatomu and Eric VW like this.
  11. TurboDiesel

    TurboDiesel

    Joined:
    Nov 22, 2013
    Messages:
    13,252
    Likes Received:
    76,668
    Location:
    Hollidaysburg Pa
    I'd recommend regular bolts over SS.
    SS will gall from heat and not come apart anyhow. Save the cash and use Elcheapo hardware:handshake:

    brenndatomu, BrianK and Eric VW like this.
  12. Eric VW

    Eric VW Moderator

    Joined:
    Jan 6, 2015
    Messages:
    21,788
    Likes Received:
    121,589
    Location:
    Southwest VA
    brenndatomu and BrianK like this.
  13. BrianK

    BrianK

    Joined:
    Oct 3, 2013
    Messages:
    2,803
    Likes Received:
    9,210
    Location:
    West central PA
    You too! Not around the forum much any more with my duties here in Massachusetts but TurboDiesel sent me a text with a link to this thread. Thanks Tim!

    Spent an awesome day riding in the Berkshire mountains of Massachusetts today, almost 5 hours on the bike. Beautiful weather, already feels like fall, my favorite time of the year to ride. 674662C3-5C7A-41E9-829A-64FBD1C6A989.jpeg

    Last edited: Aug 25, 2019
    brenndatomu, Eric VW and TurboDiesel like this.
  14. TurboDiesel

    TurboDiesel

    Joined:
    Nov 22, 2013
    Messages:
    13,252
    Likes Received:
    76,668
    Location:
    Hollidaysburg Pa
    :yes:

    brenndatomu and Eric VW like this.
  15. brenndatomu

    brenndatomu

    Joined:
    May 29, 2015
    Messages:
    11,513
    Likes Received:
    71,809
    Location:
    NE Ohio
    A coat of anti-seize will solve that...especially nickel anti-seize...it has a ~2500*F temp rating (which is 2-300* more than "standard" AS) once coated they will easily come apart in the future.
    All the internal firebox metal and fasteners on the Kuuma furnaces are stainless...when doing my summer inspection I can often spin the bolts/nuts apart by hand after broke loose with a wrench.

    Chaz likes this.
